ER18/3.2/10-3C97-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
PLANAR ER CORES 2PC SET
PDF
/
Inventory: 7867
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Supplier Device Package ER 18 x 3.2 x 10
Material 3C97
Technical
Tolerance ±25%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Finish Uncoated
Core Type ER
Gap Ungapped
Effective Area (Ae) mm2 30.2
Effective Length (le) mm 22.1
Effective Magnetic Volume (Ve) mm3 667
Core Factor (ΣI/A) mm1 0.73
Minimum Core Cross Section (Amin) mm2 30.1
Dimensions
Height 9.70mm
Length 18.00mm
Width 3.15mm
Compliance
RoHS Status ROHS3 Compliant
