ER11/2.5/6-3C92-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
PLANAR ER CORES 2PC SET
PDF
/
Inventory: 3608
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Supplier Device Package ER 11 x 2.5 x 6
Material 3C92
Technical
Tolerance ±25%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Finish Uncoated
Core Type ER
Gap Ungapped
Effective Area (Ae) mm2 11.9
Effective Length (le) mm 14.7
Effective Magnetic Volume (Ve) mm3 174
Core Factor (ΣI/A) mm1 1.23
Minimum Core Cross Section (Amin) mm2 10.3
Dimensions
Height 6.00mm
Length 11.00mm
Width 2.45mm
Compliance
RoHS Status ROHS3 Compliant
