EPX8-3C96
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
EP AND EPX CORES 2PC SET
PDF
/
Inventory: 8849
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 8.50mm
Length 9.40mm
Height 9.00mm
Technical
Minimum Core Cross Section (Amin) mm2 14.5
Core Factor (ΣI/A) mm1 1.04
Effective Magnetic Volume (Ve) mm3 279
Effective Length (le) mm 17
Effective Area (Ae) mm2 16.4
Gap Ungapped
Core Type EPX
Finish Uncoated
Part Status Active
Tolerance ±25%
Physical
Material 3C96
Supply Chain
Factory Lead Time 7 Weeks
