EP17-3C90
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
EP AND EPX CORES 2PC SET
PDF
/
Inventory: 7439
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 11.00mm
Length 18.00mm
Height 16.80mm
Technical
Minimum Core Cross Section (Amin) mm2 25.5
Core Factor (ΣI/A) mm1 0.87
Effective Magnetic Volume (Ve) mm3 999
Effective Length (le) mm 29.5
Effective Area (Ae) mm2 33.7
Gap Ungapped
Core Type EP
Finish Uncoated
Part Status Active
Physical
Material 3C90
Supplier Device Package EP 17
Supply Chain
Factory Lead Time 7 Weeks
Alternative Model
