EP13-3F46
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
EP AND EPX CORES 2PC SET
PDF
/
Inventory: 5839
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Supplier Device Package EP 13
Material 3F46
Technical
Tolerance ±25%
Part Status Active
Finish Uncoated
Core Type EP
Gap Ungapped
Effective Area (Ae) mm2 19.5
Effective Length (le) mm 24.2
Effective Magnetic Volume (Ve) mm3 472
Core Factor (ΣI/A) mm1 1.24
Minimum Core Cross Section (Amin) mm2 14.9
Dimensions
Height 9.00mm
Length 13.00mm
Width 12.80mm
Compliance
RoHS Status ROHS3 Compliant
