EFD15/8/5-3C96-A100-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
EFD CORES 2PC SET
PDF
/
Inventory: 10024
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4.65mm
Length 15.00mm
Height 7.50mm
Technical
Effective Permeability (μe) 180
Inductance Factor (Al) 100nH
Minimum Core Cross Section (Amin) mm2 12.2
Core Factor (ΣI/A) mm1 2.27
Effective Magnetic Volume (Ve) mm3 510
Effective Length (le) mm 34
Effective Area (Ae) mm2 15
Gap Gapped
Core Type EFD
Finish Uncoated
Part Status Active
Tolerance ±6%
Physical
Material 3C96
Supplier Device Package EFD 15 x 8 x 5
Supply Chain
Factory Lead Time 7 Weeks
Alternative Model
