EFD12/6/3.5-3F36-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
FERRITE CORE 2PC SET
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.3816
≥1 USD $1.3816
≥10 USD $1.19064
≥100 USD $0.90464
≥500 USD $0.856944
≥1000 USD $0.8382
Inventory: 703
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Supplier Device Package EFD 12 x 6 x 3.5
Material 3F36
Technical
Tolerance ±25%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type EFD
Gap Ungapped
Effective Area (Ae) mm2 11.4
Effective Length (le) mm 28.5
Effective Magnetic Volume (Ve) mm3 325
Core Factor (ΣI/A) mm1 2.5
Minimum Core Cross Section (Amin) mm2 10.7
Effective Permeability (μe) 1130
Dimensions
Height 6.20mm
Length 12.50mm
Width 3.50mm
Compliance
RoHS Status ROHS3 Compliant
