EFD12/6/3.5-3C96-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
EFD CORES 2PC SET
PDF
/
Inventory: 7425
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Supplier Device Package EFD 12 x 6 x 3.5
Material 3C96
Technical
Tolerance ±25%
Part Status Active
Finish Uncoated
Core Type EFD
Gap Ungapped
Effective Area (Ae) mm2 11.4
Effective Length (le) mm 28.5
Effective Magnetic Volume (Ve) mm3 325
Core Factor (ΣI/A) mm1 2.5
Minimum Core Cross Section (Amin) mm2 10.7
Effective Permeability (μe) 1490
Dimensions
Height 6.20mm
Length 12.50mm
Width 3.50mm
Compliance
RoHS Status ROHS3 Compliant
