EFD10/5/3-3F46-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
FERRITE CORE 2PC SET
PDF
/
Buying Options
Total Price: USD $1.86
Unit Price: USD $1.862786
≥1 USD $1.862786
≥10 USD $1.757337
≥100 USD $1.657872
≥500 USD $1.564035
≥1000 USD $1.4755
Inventory: 1199
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Supplier Device Package EFD 10 x 5 x 3
Material 3F46
Technical
Published 2016
Tolerance ±25%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type EFD
Gap Ungapped
Effective Area (Ae) mm2 7.2
Effective Length (le) mm 23.7
Effective Magnetic Volume (Ve) mm3 171
Core Factor (ΣI/A) mm1 3.29
Minimum Core Cross Section (Amin) mm2 6.5
Effective Permeability (μe) 655
Dimensions
Height 5.20mm
Length 10.50mm
Width 2.70mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
