9498205002
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Cores & Accessories 98 Planar EE Core Ind 8800 nH 25% TOL
PDF
/
Inventory: 4157
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Technical
Packaging Bulk
Tolerance ±25%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Inductance 8.8 μH
Test Frequency 1kHz
Finish Uncoated
Core Type E
Gap Ungapped
Effective Area (Ae) mm2 190
Effective Length (le) mm 52.9
Effective Magnetic Volume (Ve) mm3 10100
Core Factor (ΣI/A) mm1 30
Initial Permeability (μi) 2400
Minimum Core Cross Section (Amin) mm2 180
Dimensions
Height 8.26mm
Length 38.10mm
Width 25.40mm
Compliance
RoHS Status ROHS3 Compliant
