9478116002
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Cores & Accessories 78 E Core E55/21 Ind 6500 nH 25% TOL
PDF
/
Buying Options
Total Price: USD $7.13
Unit Price: USD $7.132694
≥1 USD $7.132694
≥10 USD $6.728958
≥100 USD $6.348077
≥500 USD $5.988751
≥1000 USD $5.649761
Inventory: 1154
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Material 78
Technical
Packaging Bulk
Published 2014
Tolerance ±25%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Inductance 6.5 μH
Test Frequency 1kHz
Finish Uncoated
Core Type E
Gap Ungapped
Effective Area (Ae) mm2 349
Effective Length (le) mm 124
Effective Magnetic Volume (Ve) mm3 43100
Core Factor (ΣI/A) mm1 35
Initial Permeability (μi) 2300
Minimum Core Cross Section (Amin) mm2 342
Dimensions
Height 20.6mm
Length 55.15mm
Width 27.5mm
Compliance
RoHS Status ROHS3 Compliant
