ILBB-0805150+-25%
RoHS
/
Package /
Category Filters / Ferrite Beads and Chips
Description
PDF
/
Inventory: 1735
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type SURFACE MOUNT
Material Ferrite
Technical
Packaging Cut Tape
JESD-609 Code e3
Pbfree Code yes
ECCN Code EAR99
Terminal Finish Tin (Sn)
Additional Feature NICKEL BARRIER TERMINATION
HTS Code 8504.50.80.00
Subcategory Other Passive Filters
Packing Method TAPE AND REEL
Number of Functions 1
Construction Multilayer Chip
Current Rating 300mA
Operating Temperature (Max) 125°C
Physical Dimension L2XB1.25XH0.9 (mm)/L0.079XB0.049XH0.035 (inch)
Operating Temperature (Min) -55°C
Frequency (Max) 100MHz
Filter Type FERRITE BEAD
DC Resistance (DCR) (Max) 0.15Ohm
Output Impedance 150Ohm Ω
Frequency (Min) 100MHz
Case Code 0805
Dimensions
Height 0.9mm
Length 2mm
Width 1.25mm
Compliance
RoHS Status RoHS Compliant
