BMB2A1000BN3
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Filters / Ferrite Beads and Chips
Description
TE CONNECTIVITY / SIGMA INDUCTORS BMB2A1000BN3 FERRITE BEAD, 0.8OHM, 200MA, 0805
PDF
/
Inventory: 9005
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 44 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Number of Pins 2
Material Ferrite
Weight 5.499807mg
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2007
Series BMB-B
Size / Dimension 0.079Lx0.047W 2.00mmx1.20mm
Tolerance 25%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Resistance 700mOhm
HTS Code 8504.50.80.00
Subcategory Other Filters
Shielding Shielded
Number of Functions 1
Depth 1.2mm
Construction Multilayer Chip
Current Rating 200mA
Case Code (Metric) 2012
Case Code (Imperial) 0805
ELV Compliant
Test Frequency 100MHz
Impedance 1kOhm
Max DC Current 200mA
Lead/Base Style SMD/SMT
Filter Type FERRITE CHIP
Number of Lines 1
DC Resistance (DCR) (Max) 800mOhm
Impedance @ Frequency 1kOhm @ 100MHz
Dimensions
Height 900μm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Alternative Model
