BMB2A0300LN2
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Filters / Ferrite Beads and Chips
Description
SIGMAINDUCTORS - TE CONNECTIVITY - BMB2A0300LN2 - FERRITE BEAD, 0.15OHM, 600mA, 0805
PDF
/
Inventory: 1137
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Height 900μm
Technical
Impedance @ Frequency 300Ohm @ 100MHz
DC Resistance (DCR) (Max) 150mOhm
Number of Lines 1
Lead/Base Style SMD/SMT
Max DC Current 600mA
Impedance 300Ohm
Test Frequency 100MHz
ELV Compliant
Case Code (Imperial) 0805
Case Code (Metric) 2012
Current Rating 600mA
Construction Multilayer Chip
Depth 1.4mm
Number of Functions 1
Packing Method TR
Subcategory Other Filters
Resistance 200mOhm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance 25%
Size / Dimension 0.079Lx0.047W 2.00mmx1.20mm
Series BMB-L
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Core Material Ferrite
Number of Pins 2
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 13 Weeks
