BLM41PG102SN1L

Murata Electronics
RoHS
RoHS RoHS compliant
Package 1806 (4516 Metric)
Category Filters / Ferrite Beads and Chips
Description Ferrite Beads Multi-Layer 1KOhm 25% 100MHz 1.5A 90mOhm DCR 1806 T/R
PDF
/
Buying Options
Total Price: USD $0.31
Unit Price: USD $0.308
≥1 USD $0.308
≥10 USD $0.2464
≥100 USD $0.208032
≥500 USD $0.18304
≥1000 USD $0.16368
≥3000 USD $0.142525
Inventory: 90827
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 8 Weeks
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)

Physical

Mounting Type Surface Mount
Package / Case 1806 (4516 Metric)
Material Ferrite, Steel
Core Material Ferrite

Technical

Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series EMIFIL?, BLM41
Size / Dimension 0.177Lx0.063W 4.50mmx1.60mm
Tolerance 25%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
HTS Code 8504.50.80.00
Subcategory Other Filters
Shielding Unshielded
Number of Functions 1
Depth 1.6mm
Construction Chip Bead
Current Rating 1.5A
Frequency 100MHz
Military Standard Not
Case Code (Metric) 4516
Case Code (Imperial) 1806
Test Frequency 100MHz
Impedance 1kOhm
Max DC Current 1.5A
Filter Type Power Line
DC Current 1.5A
Number of Lines 1
DC Resistance (DCR) (Max) 90mOhm
Impedance @ Frequency 1kOhm @ 100MHz

Dimensions

Height 1.6mm
Length 4.5mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
