BLM31PG601SN1L
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Filters / Ferrite Beads and Chips
Description
FERRITE BEAD 600 OHM 1206 1LN
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.2552
≥1 USD $0.2552
≥10 USD $0.198
≥100 USD $0.164384
≥500 USD $0.14168
≥1000 USD $0.127424
≥3000 USD $0.107642
Inventory: 803329
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 1.3mm
Technical
Saturation Current 1.5A
Impedance @ Frequency 600Ohm @ 100MHz
DC Resistance (DCR) (Max) 80mOhm
Number of Lines 1
Series Resistance 80mOhm
RMS Current (Irms) 1.5A
DC Current 1.5A
Filter Type Power Line
Max DC Current 1.5A
Impedance 600Ohm
Test Frequency 100MHz
Case Code (Imperial) 1206
Case Code (Metric) 3216
Military Standard Not
Frequency 100MHz
Current Rating 1.5A
Construction Chip Bead
Depth 1.6mm
Number of Functions 1
Shielding Unshielded
Subcategory Other Filters
HTS Code 8504.50.80.00
Resistance 90mOhm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.126Lx0.063W 3.20mmx1.60mm
Series EMIFIL?, BLM31
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Core Material Ferrite
Weight 10.007382mg
Material Ferrite, Steel
Number of Pins 2
Package / Case 1206 (3216 Metric)
Mounting Type Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 8 Weeks
