BLM21PG600SN1D
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Filters / Ferrite Beads and Chips
Description
MURATA - BLM21PG600SN1D - Ferrite Bead, 0805 [2012 Metric], 60 ohm, 3.5 A, BLM21P Series, 0.02 ohm, ± 25%
PDF
/
Buying Options
Total Price: USD $0.02
Unit Price: USD $0.0171
≥1 USD $0.0171
≥10 USD $0.01425
≥100 USD $0.0133
≥500 USD $0.0133
≥1000 USD $0.01235
Inventory: 290625
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 850μm
Technical
Impedance @ Frequency 60Ohm @ 100MHz
DC Resistance (DCR) (Max) 20mOhm
Number of Lines 1
DC Current 3A
Filter Type Power Line
Max DC Current 3A
Impedance 60Ohm
Test Frequency 100MHz
Case Code (Imperial) 0805
Case Code (Metric) 2012
Military Standard Not
Frequency 100MHz
Current Rating 3.5A
Construction Chip Bead
Depth 1.25mm
Number of Functions 1
Shielding Unshielded
Packing Method TAPE AND REEL
Subcategory Other Filters
HTS Code 8504.50.80.00
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Resistance 25mOhm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Series EMIFIL?, BLM21
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Core Material Ferrite
Material Ferrite, Steel
Number of Pins 2
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 7 Weeks
