BLM21PG221SN1D
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Filters / Ferrite Beads and Chips
Description
FERRITE BEAD 220 OHM 0805 1LN
PDF
/
Buying Options
Total Price: USD $0.11
Unit Price: USD $0.1056
≥1 USD $0.1056
≥10 USD $0.08536
≥100 USD $0.076736
≥500 USD $0.05632
≥1000 USD $0.048576
≥3000 USD $0.038333
Inventory: 923305
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 850μm
Technical
Impedance @ Frequency 220Ohm @ 100MHz
DC Resistance (DCR) (Max) 45mOhm
Number of Lines 1
DC Current 2A
Filter Type Power Line
Max DC Current 2A
Current 2A
Impedance 220Ohm
Test Frequency 100MHz
Case Code (Imperial) 0805
Case Code (Metric) 2012
Military Standard Not
Frequency 100MHz
Current Rating 2A
Construction Chip Bead
Depth 1.25mm
Number of Functions 1
Shielding Unshielded
Packing Method TAPE AND REEL
Subcategory Other Filters
HTS Code 8504.50.80.00
Resistance 50mOhm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Series EMIFIL?, BLM21
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Core Material Ferrite
Material Ferrite, Steel
Number of Pins 2
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 7 Weeks
