BLM21AG471SH1D
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Filters / Ferrite Beads and Chips
Description
EMI Filter Beads, Chips & Arrays 0805 470ohms Gen Use Tape
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.1672
≥1 USD $0.1672
≥10 USD $0.13992
≥100 USD $0.108768
≥500 USD $0.090112
≥1000 USD $0.077704
≥3000 USD $0.062163
Inventory: 1144
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Length 2mm
Height 1.0414mm
Technical
Impedance @ Frequency 470Ohm @ 100MHz
Current Rating (Max) 700mA
DC Resistance (DCR) (Max) 190mOhm
Number of Lines 1
Rated Current 0.2A
Filter Type FERRITE CHIP
Max DC Current 200mA
Impedance 470Ohm
Test Frequency 100MHz
Case Code (Imperial) 0805
Case Code (Metric) 2012
Construction Chip Bead
Number of Functions 1
Shielding Unshielded
Subcategory Other Filters
HTS Code 8504.50.80.00
Resistance 470Ohm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Series EMIFIL?, BLM21
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Material Ferrite
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 4 weeks ago)
Factory Lead Time 7 Weeks
