BLM18PG330SH1D
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Filters / Ferrite Beads and Chips
Description
Ferrite Beads 0603 33ohms Power Supply Tape
PDF
/
Buying Options
Total Price: USD $0.01
Unit Price: USD $0.01425
≥1 USD $0.01425
≥10 USD $0.0114
≥100 USD $0.0114
≥500 USD $0.01045
≥1000 USD $0.01045
≥20000 USD $0.0095
Inventory: 231599
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Width 0.8mm
Height 939.8μm
Technical
Impedance @ Frequency 33Ohm @ 100MHz
DC Resistance (DCR) (Max) 25mOhm
Number of Lines 1
Rated Current 1A
Filter Type Power Line
Max DC Current 3A
Impedance 33Ohm
Test Frequency 100MHz
Case Code (Imperial) 0603
Case Code (Metric) 1608
Construction Chip Bead
Number of Functions 1
Shielding Unshielded
Packing Method TR, PAPER, 7 INCH
Subcategory Other Filters
HTS Code 8504.50.80.00
Resistance 33Ohm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.063Lx0.032W 1.60mmx0.80mm
Series EMIFIL?, BLM18
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Material Ferrite
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 6 Weeks
