BLM18HK601SN1D
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Filters / Ferrite Beads and Chips
Description
Ferrite Beads Multi-Layer 600Ohm 25% 100MHz 100mA 900mOhm DCR 0603 Paper T/R
PDF
/
Buying Options
Total Price: USD $0.16
Unit Price: USD $0.1584
≥1 USD $0.1584
≥10 USD $0.13024
≥100 USD $0.101376
≥500 USD $0.084128
≥1000 USD $0.072512
≥3000 USD $0.05801
Inventory: 12356
Minimum: 1
-
+
Technical Details
Technical
Current Rating 100mA
Case Code (Metric) 1608
Case Code (Imperial) 0603
Test Frequency 100MHz
Impedance 600Ohm
Max DC Current 100mA
Number of Lines 1
DC Resistance (DCR) (Max) 900mOhm
Impedance @ Frequency 600Ohm @ 100MHz
Construction Chip Bead
Depth 950μm
Number of Functions 1
Shielding Unshielded
Subcategory Other Passive Filters
HTS Code 8504.50.80.00
Additional Feature MONOLITHIC TYPE
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Resistance 900mOhm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.063Lx0.032W 1.60mmx0.80mm
Series EMIFIL?, BLM18
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Dimensions
Height 800μm
Width 0.8mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Core Material Ferrite
Material Steel
Number of Pins 2
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 8 Weeks
