BLM18HD102SH1D
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Filters / Ferrite Beads and Chips
Description
Ferrite Beads 0603 1Kohms GHz Hi Speed Sig Line Tape
PDF
/
Buying Options
Total Price: USD $0.18
Unit Price: USD $0.176
≥1 USD $0.176
≥10 USD $0.14344
≥100 USD $0.111584
≥500 USD $0.092576
≥1000 USD $0.079728
≥3000 USD $0.063818
Inventory: 7672
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 0.8mm
Height 939.8μm
Technical
Impedance @ Frequency 1kOhm @ 100MHz
DC Resistance (DCR) (Max) 1.8Ohm
Number of Lines 1
Rated Current 0.05A
Filter Type Signal Line
Max DC Current 50mA
Impedance 1kOhm
Test Frequency 100MHz
Case Code (Imperial) 0603
Case Code (Metric) 1608
Construction Chip Bead
Number of Functions 1
Shielding Unshielded
Subcategory Other Filters
HTS Code 8504.50.80.00
Resistance 1kOhm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.063Lx0.032W 1.60mmx0.80mm
Series EMIFIL?, BLM18
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Weight 2.012816mg
Material Ferrite
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 7 Weeks
