BLM18EG601SH1D
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Filters / Ferrite Beads and Chips
Description
EMI Filter Beads, Chips & Arrays 600 OHM POWER
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2112
≥1 USD $0.2112
≥10 USD $0.16456
≥100 USD $0.136224
≥500 USD $0.117392
≥1000 USD $0.1056
≥3000 USD $0.089197
Inventory: 14685
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Lifecycle Status IN PRODUCTION (Last Updated: 4 weeks ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Material Ferrite
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series EMIFIL?, BLM18
Size / Dimension 0.063Lx0.032W 1.60mmx0.80mm
Tolerance 25%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Resistance 600Ohm
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Subcategory Other Filters
Number of Functions 1
Construction Chip Bead
Case Code (Metric) 1608
Case Code (Imperial) 0603
Test Frequency 100MHz
Impedance 600Ohm
Max DC Current 500mA
Filter Type FERRITE CHIP
Rated Current 0.5A
Number of Lines 1
DC Resistance (DCR) (Max) 350mOhm
Impedance @ Frequency 600Ohm @ 100MHz
Dimensions
Height 939.8μm
Width 0.8mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Ratings AEC-Q200
