BLM18BD221SH1D
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Filters / Ferrite Beads and Chips
Description
Ferrite Beads 0603 220ohms HiSpeed Signal Line Tape
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.02755
≥1 USD $0.02755
≥10 USD $0.0228
≥100 USD $0.02185
≥500 USD $0.0209
≥1000 USD $0.01995
Inventory: 4007
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Physical
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Weight 2.012816mg
Core Material Ferrite
Technical
Packaging Tape & Reel (TR)
Series EMIFIL?, BLM18
Size / Dimension 0.063Lx0.032W 1.60mmx0.80mm
Tolerance 25%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Resistance 220Ohm
Terminal Finish Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Additional Feature AEC-Q200
HTS Code 8504.50.80.00
Subcategory Other Filters
Packing Method TR, PAPER, 7 INCH
Shielding Unshielded
Number of Functions 1
Depth 950μm
Construction Chip Bead
Test Frequency 100MHz
DC Resistance (DCR) 450mOhm
Impedance 220Ohm
Max DC Current 200mA
Filter Type Differential Mode - Single
Rated Current 0.25A
Number of Lines 1
Impedance @ Frequency 220Ohm @ 100MHz
Dimensions
Height 800μm
Width 0.8mm
Compliance
RoHS Status ROHS3 Compliant
