BLM18BB100SH1D
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Filters / Ferrite Beads and Chips
Description
Ferrite Beads 0603 10ohms HiSpeed Signal Line Tape
PDF
/
Inventory: 2887
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Width 0.8mm
Height 939.8μm
Technical
Impedance @ Frequency 10Ohm @ 100MHz
Current Rating (Max) 700mA
DC Resistance (DCR) (Max) 100mOhm
Number of Lines 1
Rated Current 0.7A
Filter Type Signal Line
Max DC Current 500mA
Impedance 10Ohm
Test Frequency 100MHz
Case Code (Imperial) 0603
Case Code (Metric) 1608
Construction Chip Bead
Depth 950μm
Number of Functions 1
Shielding Unshielded
Packing Method TR, PAPER, 7 INCH
Subcategory Other Filters
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
Resistance 10Ohm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.063Lx0.032W 1.60mmx0.80mm
Series EMIFIL?, BLM18
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Core Material Ferrite
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
