BLM18AG601SH1D
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Filters / Ferrite Beads and Chips
Description
Ferrite Beads Multi-Layer 600Ohm 25% 100MHz 500mA 380mOhm DCR 0603 Automotive T/R
PDF
/
Buying Options
Total Price: USD $0.01
Unit Price: USD $0.01235
≥1 USD $0.01235
≥10 USD $0.01045
≥100 USD $0.0095
≥500 USD $0.0095
≥1000 USD $0.0095
Inventory: 23107
Minimum: 1
-
+
Technical Details
Technical
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Flat
ECCN Code EAR99
Resistance 600Ohm
HTS Code 8504.50.80.00
Subcategory Other Filters
Packing Method TR, PAPER, 7 INCH
Shielding Unshielded
Number of Functions 1
Depth 800μm
Construction Chip Bead
Current Rating 200mA
Case Code (Metric) 1608
Case Code (Imperial) 0603
Test Frequency 100MHz
Impedance 600Ohm
Max DC Current 200mA
Filter Type FERRITE CHIP
Number of Lines 1
DC Resistance (DCR) (Max) 380mOhm
Current Rating (Max) 500mA
Impedance @ Frequency 600Ohm @ 100MHz
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.063Lx0.032W 1.60mmx0.80mm
Series EMIFIL?, BLM18
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Dimensions
Height 800μm
Width 0.8mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Ratings AEC-Q200
Physical
Material Steel
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 6 Weeks
