BLM15HG601SH1D
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1005 Metric)
Category Filters / Ferrite Beads and Chips
Description
FERRITE BEAD 600 OHM 0402 1LN
PDF
/
Buying Options
Total Price: USD $0.02
Unit Price: USD $0.019948
≥1 USD $0.019948
≥10 USD $0.016122
≥100 USD $0.013996
≥500 USD $0.012721
Inventory: 6602
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0402 (1005 Metric)
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series EMIFIL?, BLM15
Size / Dimension 0.039Lx0.022W 1.00mmx0.55mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Resistance 600Ohm
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Packing Method TR, PAPER, 7 INCH
Number of Functions 1
Impedance 600Ohm
Filter Type Signal Line
Rated Current 0.3A
Number of Lines 1
DC Resistance (DCR) (Max) 700mOhm
Current Rating (Max) 300mA
Impedance @ Frequency 600Ohm @ 100MHz
Dimensions
Height 558.8μm
Width 0.5mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
