BLM15BD221SZ1D
RoHS
/
Package 0402 (1005 Metric)
Category Filters / Ferrite Beads and Chips
Description
FERRITE BEAD 220 OHM 0201 1LN
PDF
/
Inventory: 5064
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Physical
Mounting Type Surface Mount
Package / Case 0402 (1005 Metric)
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series EMIFIL?, BLM15
Size / Dimension 0.039Lx0.022W 1.00mmx0.55mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin (Sn)
Packing Method TR, PAPER, 7 INCH
Number of Functions 1
Filter Type Signal Line
Rated Current 0.3A
Number of Lines 1
DC Resistance (DCR) (Max) 400mOhm
Current Rating (Max) 300mA
Output Impedance 220Ohm Ω
Dimensions
Width 0.5mm
Height (Max) 0.022 0.55mm
Compliance
RoHS Status Non-RoHS Compliant
Ratings AEC-Q200
