BLM03HD102SN1D
RoHS
RoHS compliant
RoHS compliantPackage 0201 (0603 Metric)
Category Filters / Ferrite Beads and Chips
Description
Ferrite Beads Multi-Layer 1KOhm 25% 100MHz 120mA 2.9Ohm DCR 0201 T/R
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264
≥1 USD $0.264
≥10 USD $0.20592
≥100 USD $0.17072
≥500 USD $0.147312
≥1000 USD $0.132528
≥3000 USD $0.111936
Inventory: 186614
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 0.3mm
Length 0.6mm
Height 300μm
Technical
Impedance @ Frequency 1kOhm @ 100MHz
DC Resistance (DCR) (Max) 2.9Ohm
Number of Lines 1
Filter Type Signal Line
Max DC Current 120mA
Impedance 1kOhm
Test Frequency 100MHz
Case Code (Imperial) 0201
Case Code (Metric) 0603
Current Rating 120mA
Construction Chip Bead
Number of Functions 1
Packing Method TAPE AND REEL
Subcategory Other Filters
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
Resistance 1kOhm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.024Lx0.012W 0.60mmx0.30mm
Series EMIFIL?, BLM03
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Weight 170.097139μg
Material Steel
Number of Pins 2
Package / Case 0201 (0603 Metric)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 8 Weeks
