BLM02AX100SN1D
RoHS
RoHS compliant
RoHS compliantPackage 01005 (0402 Metric)
Category Filters / Ferrite Beads and Chips
Description
Ferrite Chip Bead 10Ohm 750mA 2-Pin 01005 Paper T/R
PDF
/
Buying Options
Total Price: USD $0.02
Unit Price: USD $0.023798
≥1 USD $0.023798
≥200 USD $0.009209
≥500 USD $0.008886
Inventory: 1488
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 0.4mm
Height 200μm
Technical
Impedance @ Frequency 10Ohm @ 100MHz
DC Resistance (DCR) (Max) 70mOhm
Number of Lines 1
Filter Type FERRITE CHIP
Max DC Current 750mA
Impedance 10Ohm
Test Frequency 100MHz
Case Code (Imperial) 1005
Case Code (Metric) 0402
Current Rating 750mA
Construction Chip Bead
Number of Functions 1
Shielding Unshielded
Packing Method TR, 7 INCH
Subcategory Other Filters
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
Resistance 10Ohm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.016Lx0.008W 0.40mmx0.20mm
Series EMIFIL?, BLM02
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Material Steel
Number of Pins 2
Package / Case 01005 (0402 Metric)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 8 Weeks
