BLA2ABB220SN4D

Murata Electronics
RoHS
RoHS RoHS compliant
Package 0804 (2010 Metric), Array, 8 PC Pad
Category Filters / Ferrite Beads and Chips
Description Ferrite Beads Chip Array 22Ohm 25% 100MHz 200mA 200mOhm DCR 0804 Paper T/R
PDF
/
Buying Options
Total Price: USD $25.1
Unit Price: USD $25.09805
≥1 USD $25.09805
≥10 USD $20.59315
≥100 USD $19.95
≥500 USD $19.30685
≥1000 USD $18.66275
Inventory: 1625
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Width 1mm
Height 609.6μm

Technical

Impedance @ Frequency 22Ohm @ 100MHz
DC Resistance (DCR) (Max) 200mOhm
Number of Lines 4
Filter Type Signal Line
Max DC Current 200mA
Impedance 22Ohm
Test Frequency 100MHz
Physical Dimension L2.0XB1.0XH0.5 (mm)/L0.079XB0.039XH0.02 (inch)
Case Code (Imperial) 0804
Case Code (Metric) 2010
Current Rating 200mA
Depth 1.2mm
Number of Functions 4
Shielding Unshielded
Additional Feature ARRAY TYPE
Terminal Finish Tin (Sn)
Resistance 22Ohm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.079Lx0.039W 2.00mmx1.00mm
Series EMIFIL?, BLA2
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Physical

Core Material Ferrite
Package / Case 0804 (2010 Metric), Array, 8 PC Pad
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status IN PRODUCTION (Last Updated: 4 weeks ago)
Factory Lead Time 7 Weeks
