BLA2AAG121SN4D
RoHS
RoHS compliant
RoHS compliantPackage 0804 (2010 Metric), Array, 8 PC Pad
Category Filters / Ferrite Beads and Chips
Description
EMIFIL? BLA2 0804 (2010Metric) Array 8PC Pad Tin (Sn) 4 Ferrite Bead 100mA 120Ohm 100MHz 1.2mm
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.4048
≥1 USD $0.4048
≥10 USD $0.32472
≥100 USD $0.274208
≥500 USD $0.241296
≥1000 USD $0.215952
≥3000 USD $0.187968
Inventory: 1451
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0804 (2010 Metric), Array, 8 PC Pad
Core Material Ferrite
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series EMIFIL?, BLA2
Size / Dimension 0.079Lx0.039W 2.00mmx1.00mm
Tolerance 25%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Resistance 120Ohm
Terminal Finish Tin (Sn)
Additional Feature ARRAY TYPE
Shielding Unshielded
Number of Functions 4
Depth 1.2mm
Current Rating 100mA
Frequency 100MHz
Case Code (Metric) 2010
Case Code (Imperial) 0804
Physical Dimension L2.0XB1.0XH0.5 (mm)/L0.079XB0.039XH0.02 (inch)
Test Frequency 100MHz
Impedance 120Ohm
Max DC Current 100mA
Number of Lines 4
DC Resistance (DCR) (Max) 500mOhm
Impedance @ Frequency 120Ohm @ 100MHz
Dimensions
Height 500μm
Width 1mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
