BL02RN2R1M2B
RoHS
RoHS compliant
RoHS compliantPackage Axial, Split Radial Bend
Category Filters / Ferrite Beads and Chips
Description
MURATA - BL02RN2R1M2B - Ferrite Bead, 7 A, BL02 Series
PDF
/
Buying Options
Total Price: USD $2.36
Unit Price: USD $2.35956
≥1 USD $2.35956
≥10 USD $2.226
≥100 USD $2.1
≥500 USD $1.98113
≥1000 USD $1.86899
≥3000 USD $1.7632
Inventory: 7739
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 3 weeks ago)
Physical
Contact Plating Copper, Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial, Split Radial Bend
Number of Pins 2
Core Material Ferrite
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Series EMIFIL?, BL02EN
Size / Dimension 0.134Dia 3.40mm
JESD-609 Code e2
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Resistance 50Ohm
Terminal Finish Tin/Copper (Sn/Cu)
HTS Code 8504.50.80.00
Shielding Unshielded
Number of Functions 1
Depth 3.6mm
Current Rating 7A
Frequency 1GHz
Military Standard Not
Lead Pitch 5mm
Lead Diameter 650 μm
Impedance 50Ohm
Max DC Current 7A
Lead/Base Style Radial
DC Current 7A
Number of Lines 1
DC Resistance (DCR) (Max) 20mOhm
Dimensions
Diameter 3.4mm
Height 7.5mm
Length 9mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
