MA3216-201T4

Bourns Inc.
RoHS
RoHS RoHS compliant
Package 1206 (3216 Metric), Array, 8 PC Pad
Category Filters / Ferrite Beads and Chips
Description MA 1206 (3216Metric) Array 8PC Pad Tin (Sn) 4 Ferrite Bead 150mA 200Ohm 100MHz 3.2mm
PDF
/
Inventory: 3264
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1206 (3216 Metric), Array, 8 PC Pad
Core Material Ferrite

Technical

Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2005
Series MA
Size / Dimension 0.126Lx0.063W 3.20mmx1.60mm
Tolerance 25%
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Resistance 200Ohm
Terminal Finish Tin (Sn)
Additional Feature NICKEL BARRIER TERMINATION
Packing Method TAPE AND REEL
Number of Functions 1
Depth 1.8mm
Base Part Number MA3216
Case Code (Metric) 3216
Case Code (Imperial) 1206
Number of Elements 8
Test Frequency 100MHz
Impedance 200Ohm
Max DC Current 150mA
Rated Current 0.15A
Number of Lines 4
DC Resistance (DCR) (Max) 300mOhm
Impedance @ Frequency 200Ohm @ 100MHz

Dimensions

Height 889μm
Length 3.2mm

Compliance

RoHS Status ROHS3 Compliant
