EMI1806R-80

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package 1806 (4516 Metric)
Category Filters / Ferrite Beads and Chips
Description Ferrite Beads EMI/RFI Suppressor Chip Bead SMT
PDF
/
Buying Options
Total Price: USD $0.99
Unit Price: USD $0.993865
≥1 USD $0.993865
≥200 USD $0.396496
≥500 USD $0.383367
≥1000 USD $0.376802
Inventory: 8317
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height (Max) 0.071 1.80mm
Width 1.6002mm
Length 4.4958mm
Height 1.8034mm

Technical

Impedance @ Frequency 80Ohms @ 100MHz
Current Rating (Max) 400mA
DC Resistance (DCR) (Max) 100mOhm
Number of Lines 1
Max DC Current 400mA
Impedance 80Ohm
Test Frequency 100MHz
Case Code (Imperial) 1806
Case Code (Metric) 4516
Depth 1.8mm
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance 25%
Size / Dimension 0.177Lx0.063W 4.50mmx1.60mm
Series EMI1806R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Physical

Core Material Ferrite
Package / Case 1806 (4516 Metric)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 10 Weeks
