EMI0805R-40
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Filters / Ferrite Beads and Chips
Description
Ferrite Beads EMI/RFI Suppressor Chip Bead SMT
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.66564
≥1 USD $0.66564
≥200 USD $0.266519
≥500 USD $0.257328
≥1000 USD $0.25339
Inventory: 8546
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 1.0922mm
Technical
Impedance @ Frequency 40Ohm @ 100MHz
DC Resistance (DCR) (Max) 50mOhm
Number of Lines 1
Rated Current 0.6A
Max DC Current 600mA
Impedance 40Ohm
Test Frequency 100MHz
Case Code (Imperial) 0805
Case Code (Metric) 2012
Construction Chip Bead
Depth 1.45mm
Number of Functions 1
Packing Method TAPE AND REEL
Subcategory Other Filters
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Series EMI0805R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Core Material Ferrite
Package / Case 0805 (2012 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
