EMI0603R-60
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Filters / Ferrite Beads and Chips
Description
Ferrite Beads EMI/RFI Suppressor Chip Bead SMT
PDF
/
Buying Options
Total Price: USD $0.65
Unit Price: USD $0.651198
≥1 USD $0.651198
≥200 USD $0.259954
≥500 USD $0.252077
≥1000 USD $0.246825
Inventory: 8835
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 0.8mm
Height 939.8μm
Technical
Impedance @ Frequency 60Ohm @ 100MHz
DC Resistance (DCR) (Max) 100mOhm
Number of Lines 1
Rated Current 0.6A
Max DC Current 600mA
Impedance 60Ohm
Test Frequency 100MHz
Case Code (Imperial) 0603
Case Code (Metric) 1608
Construction Chip Bead
Depth 950μm
Number of Functions 1
Shielding Shielded
Packing Method TAPE AND REEL
Subcategory Other Filters
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 25%
Size / Dimension 0.063Lx0.032W 1.60mmx0.80mm
Series EMI0603R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Core Material Ferrite
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
Alternative Model
