FN7513-16-M4
RoHS
RoHS compliant
RoHS compliantPackage Axial - Threaded Terminals
Category Filters / Feed Through Capacitors
Description
CAP FEEDTHRU 0.1UF 20% 1KV AXIAL
PDF
/
Buying Options
Total Price: USD $49.93
Unit Price: USD $49.9312
≥1 USD $49.9312
Inventory: 376
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Package / Case Axial - Threaded Terminals
Technical
Operating Temperature -40°C~100°C
Packaging Tray
Published 2014
Series FN 751X
Size / Dimension 1.061Diax3.031L 26.95mmx77.00mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Voltage - Rated 1000V 1kV
Capacitance 0.1μF
Current Rating 6A
Approval Agency UL; ENEC-14
Physical Dimension D26.95XH30.85 (mm)/D1.061XH1.215 (inch)
Operating Frequency 50/60Hz Hz
Voltage 250V
Current 16A
Filter Type AC FEED THROUGH CAPACITOR
Thread Size M16x2
DC Resistance (DCR) (Max) 0.58mOhm Typ
Insulation Resistance-Min 1500MOhm
High Pot 3000 V
Dimensions
Diameter 26.95mm
Height 30.85mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
Ratings Y2
