NFM41CC471R2A3L
RoHS
RoHS compliant
RoHS compliantPackage 1806 (4516 Metric), 3 PC Pad
Category Filters / Feed Through Capacitors
Description
MURATA NFM41CC471R2A3L CAPACITOR, 3 TERMINAL, 470PF
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.396
≥1 USD $0.396
≥10 USD $0.37752
≥100 USD $0.365024
≥500 USD $0.352704
≥1000 USD $0.334488
≥3000 USD $0.27977
Inventory: 1465
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 4.5mm
Height 1mm
Technical
DC Resistance (DCR) (Max) 300mOhm
Filter Type FEED THROUGH CAPACITOR
Max Voltage Rating (DC) 100V
Max Current Rating 300mA
Voltage 100V
Insulation Resistance 1GOhm
Physical Dimension L4.5XB1.6XH1.0 (mm)/L0.177XB0.063XH0.039 (inch)
Case Code (Imperial) 1806
Case Code (Metric) 4516
Voltage - Rated AC 100V
Current Rating 300mA
Depth 1.6mm
Number of Functions 1
Packing Method TR
Voltage - Rated DC 100V
Capacitance 470pF
HTS Code 8504.50.80.00
Additional Feature C-TYPE CIRCUIT
Terminal Finish Tin (Sn)
Resistance 300mOhm
ECCN Code EAR99
Termination Flat
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance -20% +50%
Size / Dimension 0.177Lx0.063W 4.50mmx1.60mm
Series EMIFIL?, NFM41
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Package / Case 1806 (4516 Metric), 3 PC Pad
Mounting Type Surface Mount
Mount PCB, Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 10 Weeks
