NFM41CC222R2A3L
RoHS
RoHS compliant
RoHS compliantPackage 1806 (4516 Metric), 3 PC Pad
Category Filters / Feed Through Capacitors
Description
MURATA NFM41CC222R2A3L CAPACITOR, 3 TERMINAL, 2200PF
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.26885
≥1 USD $0.26885
≥10 USD $0.2204
≥100 USD $0.21375
≥500 USD $0.2071
≥1000 USD $0.20045
Inventory: 737
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Physical
Mount PCB, Surface Mount
Mounting Type Surface Mount
Package / Case 1806 (4516 Metric), 3 PC Pad
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series EMIFIL?, NFM41
Size / Dimension 0.177Lx0.063W 4.50mmx1.60mm
Tolerance -20% +50%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Flat
ECCN Code EAR99
Resistance 300mOhm
Terminal Finish Tin (Sn)
Additional Feature C-TYPE CIRCUIT
HTS Code 8504.50.80.00
Capacitance 2200pF
Voltage - Rated DC 100V
Packing Method TAPE AND REEL
Number of Functions 1
Depth 1.6mm
Current Rating 300mA
Voltage - Rated AC 100V
Case Code (Metric) 4516
Case Code (Imperial) 1806
Physical Dimension L4.5XB1.6XH1.0 (mm)/L0.177XB0.063XH0.039 (inch)
Insulation Resistance 10GOhm
Voltage 100V
Max Current Rating 300mA
Max Voltage Rating (DC) 100V
Filter Type FEED THROUGH CAPACITOR
DC Resistance (DCR) (Max) 300mOhm
Dimensions
Height 1mm
Length 4.5mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
