NFM41CC101U2A3L
RoHS
/
Package 1806 (4516 Metric), 3 PC Pad
Category Filters / Feed Through Capacitors
Description
Feed Through Capacitors 100PF 100V 0.3A EMI
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5377
≥1 USD $0.5377
≥10 USD $0.4408
≥100 USD $0.4275
≥500 USD $0.41325
≥1000 USD $0.39995
Inventory: 15808
Minimum: 1
-
+
Technical Details
Physical
Mount PCB, Surface Mount
Mounting Type Surface Mount
Package / Case 1806 (4516 Metric), 3 PC Pad
Number of Pins 1806
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series EMIFIL?, NFM41
Size / Dimension 0.177Lx0.063W 4.50mmx1.60mm
Tolerance -20% +50%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Flat
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Voltage - Rated 100V
Capacitance 100pF
Voltage - Rated DC 100V
Depth 1.6mm
Current Rating 300mA
Case Code (Metric) 4516
Case Code (Imperial) 1806
Insulation Resistance 10GOhm
Voltage 100V
Max Current Rating 300mA
DC Resistance (DCR) 300mOhm
Current 300mA
Max Voltage Rating (DC) 100V
Dimensions
Height 1mm
Length 4.5mm
Width 1.6002mm
Height (Max) 0.047 1.20mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
