NFM3DCC470U1H3L
RoHS
/
Package 1205 (3212 Metric), 3 PC Pad
Category Filters / Feed Through Capacitors
Description
CAPACITOR, 3 TERMINAL, 47PF
PDF
/
Buying Options
Total Price: USD $0.12
Unit Price: USD $0.1197
≥1 USD $0.1197
≥10 USD $0.0988
≥100 USD $0.095
≥500 USD $0.09215
≥1000 USD $0.0893
≥10000 USD $0.0798
Inventory: 1613
Minimum: 1
-
+
Technical Details
Physical
Mount PCB, Surface Mount
Mounting Type Surface Mount
Package / Case 1205 (3212 Metric), 3 PC Pad
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series EMIFIL?, NFM3
Size / Dimension 0.126Lx0.049W 3.20mmx1.25mm
Tolerance -20% +50%
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Flat
ECCN Code EAR99
Resistance 600mOhm
Terminal Finish Tin (Sn)
Additional Feature C-TYPE CIRCUIT
HTS Code 8504.50.80.00
Capacitance 47pF
Voltage - Rated DC 50V
Packing Method TAPE AND REEL
Number of Functions 1
Depth 1.25mm
Current Rating 200mA
Case Code (Metric) 3212
Case Code (Imperial) 1205
Physical Dimension L3.2XB1.25XH0.7 (mm)/L0.126XB0.049XH0.028 (inch)
Insulation Resistance 1GOhm
Voltage 50V
Max Current Rating 300mA
DC Resistance (DCR) 300mOhm
Max Voltage Rating (DC) 50V
Filter Type FEED THROUGH CAPACITOR
Dimensions
Height 889μm
Length 3.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
