NFM31PC276B0J3L
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric), 3 PC Pad
Category Filters / Feed Through Capacitors
Description
EMI Filter C-Circuit 6A 6.3VDC Flat Style SMD Embossed T/R
PDF
/
Buying Options
Total Price: USD $0.79
Unit Price: USD $0.792
≥1 USD $0.792
≥10 USD $0.77
≥100 USD $0.629024
≥500 USD $0.564784
≥1000 USD $0.513392
≥3000 USD $0.487766
Inventory: 18300
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 3.2mm
Height 1.3mm
Technical
DC Resistance (DCR) (Max) 5mOhm
Filter Type FEED THROUGH CAPACITOR
Max Voltage Rating (DC) 6.3V
Max Current Rating 6A
Voltage 6.3V
Insulation Resistance 20MOhm
Physical Dimension L3.2XB1.6XH1.3 (mm)/L0.126XB0.063XH0.051 (inch)
Case Code (Imperial) 1206
Case Code (Metric) 3216
Current Rating 6A
Depth 1.6mm
Number of Functions 1
Packing Method TAPE AND REEL
Voltage - Rated DC 6.3V
Capacitance 27μF
HTS Code 8504.50.80.00
Additional Feature C-TYPE CIRCUIT
ECCN Code EAR99
Termination Flat
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Tolerance ±20%
Size / Dimension 0.126Lx0.063W 3.20mmx1.60mm
Series EMIFIL?, NFM31
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Package / Case 1206 (3216 Metric), 3 PC Pad
Mounting Type Surface Mount
Mount PCB, Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 10 Weeks
