NFM21PC474R1C3D
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric), 3 PC Pad
Category Filters / Feed Through Capacitors
Description
MURATA - NFM21PC474R1C3D - Feedthrough Capacitor, Three Terminal, 0.47 μF, 16 V, 2 A, 0805 [2012 Metric], Surface Mount, ± 20%
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.1408
≥1 USD $0.1408
≥10 USD $0.13816
≥100 USD $0.133408
≥500 USD $0.129008
≥1000 USD $0.122408
≥3000 USD $0.102362
Inventory: 62127
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 2mm
Height 850μm
Technical
DC Resistance (DCR) (Max) 30mOhm
Filter Type FEED THROUGH CAPACITOR
Max Voltage Rating (DC) 16V
Max Current Rating 2A
Voltage 16V
Insulation Resistance 1GOhm
Physical Dimension L2.0XB1.25XH0.85 (mm)/L0.079XB0.049XH0.033 (inch)
Case Code (Imperial) 0805
Case Code (Metric) 2012
Voltage - Rated AC 16V
Current Rating 2A
Depth 1.25mm
Number of Functions 1
Packing Method TR, PAPER, 7 INCH
Voltage - Rated DC 16V
Capacitance 0.47μF
HTS Code 8504.50.80.00
Additional Feature C-TYPE CIRCUIT
Terminal Finish Tin (Sn)
ECCN Code EAR99
Termination Flat
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Series EMIFIL?, NFM21
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Weight 5.499807mg
Package / Case 0805 (2012 Metric), 3 PC Pad
Mounting Type Surface Mount
Mount PCB, Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 10 Weeks
