NFM21PC104R1E3D
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric), 3 PC Pad
Category Filters / Feed Through Capacitors
Description
MURATA - NFM21PC104R1E3D - Feedthrough Capacitor, Three Terminal, 0.1 μF, 25 V, 2 A, 0805 [2012 Metric], Surface Mount, ± 20%
PDF
/
Buying Options
Total Price: USD $0.07
Unit Price: USD $0.06745
≥1 USD $0.06745
≥10 USD $0.0551
≥100 USD $0.05415
≥500 USD $0.05225
≥1000 USD $0.05035
≥4000 USD $0.0456
Inventory: 180009
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 2mm
Height 850μm
Technical
DC Resistance (DCR) (Max) 30mOhm
Filter Type FEED THROUGH CAPACITOR
Max Voltage Rating (DC) 25V
Max Current Rating 2A
Voltage 25V
Insulation Resistance 1GOhm
Physical Dimension L2.0XB1.25XH0.85 (mm)/L0.079XB0.049XH0.033 (inch)
Case Code (Imperial) 0805
Case Code (Metric) 2012
Voltage - Rated AC 25V
Current Rating 2A
Depth 1.25mm
Number of Functions 1
Packing Method TAPE AND REEL
Voltage - Rated DC 25V
Capacitance 0.1μF
HTS Code 8504.50.80.00
Additional Feature C-TYPE CIRCUIT
Terminal Finish TIN
ECCN Code EAR99
Termination Flat
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Series EMIFIL?, NFM21
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Package / Case 0805 (2012 Metric), 3 PC Pad
Mounting Type Surface Mount
Mount PCB, Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 10 Weeks
