NFM21HC104R1A3D
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric), 3 PC Pad
Category Filters / Feed Through Capacitors
Description
EMI Filter C-Circuit 2A 10VDC Flat Style SMD Automotive T/R
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264
≥1 USD $0.264
≥10 USD $0.21296
≥100 USD $0.179872
≥500 USD $0.158224
≥1000 USD $0.141592
≥3000 USD $0.123235
Inventory: 1169
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Lifecycle Status IN PRODUCTION (Last Updated: 3 weeks ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric), 3 PC Pad
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series EMIFIL?, NFM21
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Flat
ECCN Code EAR99
Additional Feature C-TYPE CIRCUIT
HTS Code 8504.50.80.00
Capacitance 0.1μF
Voltage - Rated DC 10V
Packing Method TAPE AND REEL
Number of Functions 1
Depth 1.25mm
Current Rating 2A
Case Code (Metric) 2012
Case Code (Imperial) 0805
Physical Dimension L2.0XB1.25XH0.85 (mm)/L0.079XB0.049XH0.033 (inch)
Insulation Resistance 1Ohm
Voltage 10V
Max Current Rating 2A
Max Voltage Rating (DC) 10V
Filter Type FEED THROUGH CAPACITOR
DC Resistance (DCR) (Max) 30mOhm
Dimensions
Height 939.8μm
Length 2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
