SFJNL5000334MX1
RoHS
RoHS compliant
RoHS compliantPackage Axial, Bushing
Category Filters / Feed Through Capacitors
Description
EMI Feedthrough Filters 500V .33uF X7R 20% L-C FILTER
PDF
/
Buying Options
Total Price: USD $31.52
Unit Price: USD $31.520103
≥1 USD $31.520103
≥200 USD $12.198154
≥500 USD $11.768836
≥1000 USD $11.557459
Inventory: 7541
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 9.4mm
Technical
Insulation Resistance-Min 10000MOhm
Insertion Loss (Max) 70 dB
Thread Size M6x0.75
Circuit Type Filter
Max Voltage Rating (DC) 500V
Max DC Current 15A
Max Current Rating 15A
Inductance 0.5 μH
Physical Dimension D9.8XH9.4 (mm)/D0.386XH0.37 (inch)
Depth 9.8mm
Number of Functions 1
Capacitance 0.33μF
Additional Feature L-C TYPE CIRCUIT
Terminal Finish SILVER
Temperature Coefficient X7R
Termination Axial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Tolerance ±20%
Size / Dimension 0.386Diax0.370L 9.80mmx9.40mm
Series SFJN
Published 2014
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Package / Case Axial, Bushing
Mounting Type PANEL MOUNT
Supply Chain
Factory Lead Time 11 Weeks
