SFJEL2K00331MC1
RoHS
/
Package Axial, Bushing
Category Filters / Feed Through Capacitors
Description
SFJE Axial Bushing SILVER 1 Feed Through Capacitor 15A 10000MOhm 9.8mm 16dB @ 100MHz
PDF
/
Buying Options
Total Price: USD $103.69
Unit Price: USD $103.694155
≥1 USD $103.694155
≥200 USD $41.374731
≥500 USD $39.992247
≥1000 USD $39.309539
Inventory: 9244
Minimum: 1
-
+
Technical Details
Dimensions
Height 9.4mm
Diameter 9.8mm
Technical
Insulation Resistance-Min 10000MOhm
Insertion Loss 16dB @ 100MHz
Thread Size 1/4-28
Filter Type DATA LINE FILTER
Current 15A
Inductance 0.5 μH
Physical Dimension D9.8XH9.4 (mm)/D0.386XH0.37 (inch)
Reach Compliance Code compliant
Number of Functions 1
Capacitance 330pF
Additional Feature L-C TYPE CIRCUIT
Voltage - Rated 2000V 2kV
Terminal Finish SILVER
Temperature Coefficient C0G NP0
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Tolerance ±20%
Size / Dimension 0.386Diax0.370L 9.80mmx9.40mm
Series SFJE
Published 2014
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Package / Case Axial, Bushing
Mounting Type PANEL MOUNT
Supply Chain
Factory Lead Time 11 Weeks
