SFCML5000472MX1
RoHS
RoHS compliant
RoHS compliantPackage Axial, Bushing
Category Filters / Feed Through Capacitors
Description
SFCM Axial Bushing SILVER 1 Feed Through Capacitor 10A 10000MOhm 0.250Diax0.453L 6.35mmx11.50mm 39dB @ 100MHz
PDF
/
Buying Options
Total Price: USD $18.12
Unit Price: USD $18.123272
≥1 USD $18.123272
≥200 USD $7.013512
≥500 USD $6.766687
≥1000 USD $6.6459
Inventory: 5622
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type PANEL MOUNT
Package / Case Axial, Bushing
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Published 2014
Series SFCM
Size / Dimension 0.250Diax0.453L 6.35mmx11.50mm
Tolerance ±20%
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Temperature Coefficient X7R
Terminal Finish SILVER
Voltage - Rated 500V
Additional Feature L-C TYPE CIRCUIT
Capacitance 4700pF
Number of Functions 1
Inductance 0.5 μH
Current 10A
Filter Type DATA LINE FILTER
Thread Size M5x0.8
Insertion Loss 39dB @ 100MHz
Insulation Resistance-Min 10000MOhm
Compliance
RoHS Status ROHS3 Compliant
