SFCDC5000222MX1
RoHS
RoHS compliant
RoHS compliantPackage Axial, Bushing
Category Filters / Feed Through Capacitors
Description
SFCD Axial Bushing SILVER 1 Feed Through Capacitor 10A 10000MOhm 0.250Diax0.467L 6.35mmx11.85mm 30dB @ 100MHz
PDF
/
Inventory: 3075
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Insulation Resistance-Min 10000MOhm
Insertion Loss 30dB @ 100MHz
Thread Size 12-32
Filter Type FEED THROUGH CAPACITOR
Current 10A
Inductance 0.75 μH
Number of Functions 1
Capacitance 2200pF
Additional Feature C-TYPE CIRCUIT
Voltage - Rated 500V
Terminal Finish SILVER
Temperature Coefficient X7R
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Tolerance ±20%
Size / Dimension 0.250Diax0.467L 6.35mmx11.85mm
Series SFCD
Published 2014
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Package / Case Axial, Bushing
Mounting Type PANEL MOUNT
Supply Chain
Factory Lead Time 11 Weeks
